ULVAC HELIOT ZERO — Helium Leak Detector
The HELIOT ZERO is a compact ULVAC helium mass spectrometer leak detector designed for high-speed leak testing in automated production environments. It is optimised for fast cycle time rather than maximum sensitivity, making it well suited to high-throughput leak test stations on production lines.
Design Concept
The HELIOT ZERO is a module-type instrument — like the HELIOT MONO, it has no built-in display or operator controls. All operation is via the EXT.I/O interface or RS-232C serial communication. It is intended for integration into automated test machines and production cells.
The ZERO is distinguished by its emphasis on short cycle time: fast pump-down, fast helium response, and fast atmospheric recovery between test cycles. Minimum detectable leak rate is 1×10⁻¹² Pa·m³/s (Ultra Flow mode), comparable to the HELIOT MONO and 710 series.
Key Specifications
| Parameter | Value | Notes |
|---|---|---|
| Detection principle | 90° magnetic deflection mass spectrometer | Helium (mass 4) selective |
| Minimum detectable leak rate | 1×10⁻¹² Pa·m³/s | Ultra Flow mode |
| Test modes | Ultra Flow, Fine Flow, Gross Flow, Sniffing | EXT.I/O selectable |
| Control interface | EXT.I/O (open collector), RS-232C | No built-in display |
| Compatibility mode | HELIOT 700, 710, 300 signal emulation | EXT.I/O format selectable |
| Backing pump | Oil rotary-vane or dry scroll (model dependent) | Owner confirmation required |
Note: Detailed specifications for the HELIOT ZERO vary by variant. Contact us with your model and serial number for variant-specific information.
Applications
- High-throughput production line leak testing (automotive components, refrigeration parts, medical devices)
- Automated test cells where fast cycle time is critical
- Machine integration where minimum footprint is required
- Applications where PLC control is preferred over manual operator interaction
Service Support
We provide full service support for HELIOT ZERO instruments: commissioning, preventive maintenance, calibration, ion-source replacement, turbomolecular pump service, repair, and spare parts supply. All service conducted in English, on-site at your facility.
Contact
Email: mail@ulvacheliot.com
Please include your HELIOT ZERO model and serial number, fault symptoms or service required, and facility location.
